Model và thông só kĩ thuật :
| Model | Reference Distance | Measuring Range | Full Scale | Repeat Accuracy |
| MLD17-500V-485 | 105~605mm | 500mm | ±0.1% | |
| MLD23-200N | 200mm | 120~280mm | ≥ 100mm | 200um |
| MLD33-250P-422 | 250mm | 100~400mm | 300mm | 75um |
| MLD33-250N-422 | 250mm | 100~400mm | 300mm | 75um |
| MLD33-85N-422 | 85mm | 65~105mm | 40mm | 10um |
| MLD33-50N-422 | 50mm | 40~60mm | 20mm | 5um |
| MLD33-50N | 50mm | 40~60mm | 20mm | 5um |
| MLD33-L85PV | 82.9mm | 72.9~92.9mm | 20mm | 5um |
| MLD33-L85PA | 82.9mm | 72.9~92.9mm | 20mm | 5um |
| MLD33-L85P-422 | 82.9mm | 72.9~92.9mm | 20mm | 5um |
| MLD33-L85NV | 82.9mm | 72.9~92.9mm | 20mm | 5um |
| MLD33-L85NA | 82.9mm | 72.9~92.9mm | 20mm | 5um |
| MLD33-L85N-422 | 82.9mm | 72.9~92.9mm | 20mm | 5um |
| MLD33-L50PV | 47.3mm | 42.3~52.3mm | 10mm | 2.5um |
| MLD33-L50PA | 47.3mm | 42.3~52.3mm | 10mm | 2.5um |
| MLD33-L50P-422 | 47.3mm | 42.3~52.3mm | 10mm | 2.5um |
| MLD33-L50NV | 47.3mm | 42.3~52.3mm | 10mm | 2.5um |
| MLD33-L50NA | 47.3mm | 42.3~52.3mm | 10mm | 2.5um |
| MLD33-L50N-422 | 47.3mm | 42.3~52.3mm | 10mm | 2.5um |
| MLD33-L30PV | 26.3mm | 24.3~28.3mm | 4mm | 1um |
| MLD33-L30PA | 26.3mm | 24.3~28.3mm | 4mm | 1um |
| MLD33-L30P-422 | 26.3mm | 24.3~28.3mm | 4mm | 1um |
| MLD33-L30NV | 26.3mm | 24.3~28.3mm | 4mm | 1um |
| MLD33-L30NA | 26.3mm | 24.3~28.3mm | 4mm | 1um |
| MLD33-L30N-422 | 26.3mm | 24.3~28.3mm | 4mm | 1um |
| MLD33-85PV | 85mm | 65~105mm | 40mm | 10um |
| MLD33-85PA | 85mm | 65~105mm | 40mm | 10um |
| MLD33-85P-422 | 85mm | 65~105mm | 40mm | 10um |
| MLD33-85P | 85mm | 65~105mm | 40mm | 10um |
| MLD33-85NV | 85mm | 65~105mm | 40mm | 10um |
| MLD33-85NA | 85mm | 65~105mm | 40mm | 10um |
| MLD33-85N | 85mm | 65~105mm | 40mm | 10um |
| MLD33-50PV | 50mm | 40~60mm | 20mm | 5um |
| MLD33-50PA | 50mm | 40~60mm | 20mm | 5um |
| MLD33-50P-422 | 50mm | 40~60mm | 20mm | 5um |
| MLD33-50P | 50mm | 40~60mm | 20mm | 5um |
| MLD33-50NV | 50mm | 40~60mm | 20mm | 5um |
| MLD33-50NA | 50mm | 40~60mm | 20mm | 5um |
| MLD33-30PV | 30mm | 26~34mm | 8mm | 2um |
| MLD33-30PA | 30mm | 26~34mm | 8mm | 2um |
| MLD33-30P-422 | 30mm | 26~34mm | 8mm | 2um |
| MLD33-30P | 30mm | 26~34mm | 8mm | 2um |
| MLD33-30NV | 30mm | 26~34mm | 8mm | 2um |
| MLD33-30NA | 30mm | 26~34mm | 8mm | 2um |
| MLD33-30N-422 | 30mm | 26~34mm | 8mm | 2um |
| MLD33-30N | 30mm | 26~34mm | 8mm | 2um |
| MLD33-120PV | 120mm | 60-180mm | 120mm | 30um |
| MLD33-120PA | 120mm | 60-180mm | 120mm | 30um |
| MLD33-120P-422 | 120mm | 60-180mm | 120mm | 30um |
| MLD33-120P | 120mm | 60-180mm | 120mm | 30um |
| MLD33-120NV | 120mm | 60-180mm | 120mm | 30um |
| MLD33-120NA | 120mm | 60-180mm | 120mm | 30um |
| MLD33-120N | 120mm | 60-180mm | 120mm | 30um |
| MLD22-35V | 35mm | 20~50mm | 30mm | 6um |
| MLD22-35A | 35mm | 20~50mm | 30mm | 6um |
| MLD22-15V | 15mm | 10~20mm | 10mm | 1um |
| MLD22-15A | 15mm | 10~20mm | 10mm | 1um |
| MLD22-100V | 100mm | 50~150mm | 100mm | 20um |
| MLD22-100A | 100mm | 50~150mm | 100mm | 20um |
