| Model | TGF30-10PO2 |
| Type | Shielded |
| Size | M30 |
| Sensing distance | 10mm±10% |
| Material | Nickel plated brass |
| Operating Voltage | 10~30V DC(Ripple＜10%) |
| Voltage drop | ＜1.8V |
| Load Current | outer |
| No load current | ＜3mA(24v) |
| Switch frequency | 200Hz/220℃ |
| Output Type | PNP Normally Open |
| Repeat accuracy | ＜3.0%(Sr) |
| Hysteresis | 3~15%(Sr) |
| Material active face | PBT |
| Operating Temperature | -25~+220℃ |
| Shell Protection Degree | IP66 |
| Interface | PTFE cable/2m；3*0.34mm² |
| Model | TGF30-10NO2 |
| Type | Shielded |
| Size | M30 |
| Sensing distance | 10mm±10% |
| Material | Nickel plated brass |
| Operating Voltage | 10~30V DC(Ripple＜10%) |
| Voltage drop | ＜1.8V |
| Load Current | outer |
| No load current | ＜3mA(24v) |
| Switch frequency | 200Hz/220℃ |
| Output Type | NPN Normally Open |
| Repeat accuracy | ＜3.0%(Sr) |
| Hysteresis | 3~15%(Sr) |
| Material active face | PBT |
| Operating Temperature | -25~+220℃ |
| Shell Protection Degree | IP66 |
| Interface | PTFE cable/2m；3*0.34mm² |
