| Model | TRN18-08NC-E2 |
| Type | Non-Shielded |
| Size | M18 |
| Sensing distance | 8mm |
| Material | Nickel plated brass |
| Operating Voltage | 10~30V DC(Ripple＜10%) |
| Voltage drop | ＜1.5V |
| Load Current | 150mA |
| No load current | ＜20mA |
| Leakage Current | ＜0.01mA |
| Output Type | NPN Open collector， Normally Closed |
| Switch frequency | 500Hz |
| Response Time | 0.5ms |
| Repeat accuracy | ＜1.0%(Sr) |
| Switch hysteresis | ＜15%(Sr) |
| Material active face | PBT |
| Operating Temperature | -25℃~+70℃ |
| Protection | Short-circuit Protection |
| Protection Degree | IP 67 |
| Overload trip point | 180mA |
| Connection | M12/4 wires Connector |
| Model | TRN18-08PO-E2 |
| Type | Non-Shielded |
| Size | M18 |
| Sensing distance | 8mm |
| Material | Nickel plated brass |
| Operating Voltage | 10~30V DC(Ripple＜10%) |
| Voltage drop | ＜1.5V |
| Load Current | 150mA |
| No load current | ＜20mA |
| Leakage Current | ＜0.01mA |
| Output Type | PNP Open collector， Normally Open |
| Switch frequency | 500Hz |
| Response Time | 0.5ms |
| Repeat accuracy | ＜1.0%(Sr) |
| Switch hysteresis | ＜15%(Sr) |
| Material active face | PBT |
| Operating Temperature | -25℃~+70℃ |
| Protection | Short-circuit Protection |
| Protection Degree | IP 67 |
| Overload trip point | 180mA |
| Connection | M12/4 wires Connector |
| Model | TRN18-08PC-E2 |
| Type | Non-Shielded |
| Size | M18 |
| Sensing distance | 8mm |
| Material | Nickel plated brass |
| Operating Voltage | 10~30V DC(Ripple＜10%) |
| Voltage drop | ＜1.5V |
| Load Current | 150mA |
| No load current | ＜20mA |
| Leakage Current | ＜0.01mA |
| Output Type | PNP Open collector， Normally Closed |
| Switch frequency | 500Hz |
| Response Time | 0.5ms |
| Repeat accuracy | ＜1.0%(Sr) |
| Switch hysteresis | ＜15%(Sr) |
| Material active face | PBT |
| Operating Temperature | -25℃~+70℃ |
| Protection | Short-circuit Protection |
| Protection Degree | IP 67 |
| Overload trip point | 180mA |
| Connection | M12/4 wires Connector |
| Model | TRN18-08NO-E2 |
| Type | Non-Shielded |
| Size | M18 |
| Sensing distance | 8mm |
| Material | Nickel plated brass |
| Operating Voltage | 10~30V DC(Ripple＜10%) |
| Voltage drop | ＜1.5V |
| Load Current | 150mA |
| No load current | ＜20mA |
| Leakage Current | ＜0.01mA |
| Output Type | NPN Open collector， Normally Open |
| Switch frequency | 500Hz |
| Response Time | 0.5ms |
| Repeat accuracy | ＜1.0%(Sr) |
| Switch hysteresis | ＜15%(Sr) |
| Material active face | PBT |
| Operating Temperature | -25℃~+70℃ |
| Protection | Short-circuit Protection |
| Protection Degree | IP 67 |
| Overload trip point | 180mA |
| Connection | M12/4 wires Connector |
