| Model | KLM06-0304NP |
| Groove depth | 42mm |
| Slot width | 30mm |
| Sensing distance | 30mm |
| Min detector diameter | 0.05mm |
| Output Type | NPN&PNP Open collector |
| Switch Mode | L.on ( Light.ON )/D.on ( Dark.ON ) Can be customized |
| Emitting Light | Laser(670mm) Modulated light，class1 |
| Ambient illuminance | ≤10000Lux |
| Operating Voltage | 12~24V DC±10% |
| No load current | 40mA |
| Load Current | 100mA |
| Residual voltage | ＜2V@1L=100mA |
| Switch frequency | 10KHz |
| Protection | Reversed Polarity Protection, Ouptut Short-circuit Protection, Interference suppression |
| Operating Temperature | -20~+55℃ |
| Storage Temperature | -30~﹢80℃ |
| Protection Degree | IP65 |
| Material | Aluminum, Glass |
| Wiring Method | M8 4 Pin Connector |
| Weight | 55g to 128g |
| Model | KLM06-1206NP |
| Groove depth | 59mm |
| Slot width | 120mm |
| Sensing distance | 120mm |
| Min detector diameter | 0.05mm |
| Output Type | NPN&PNP Open collector |
| Switch Mode | L.on ( Light.ON )/D.on ( Dark.ON ) Can be customized |
| Emitting Light | Laser(670mm) Modulated light，class1 |
| Ambient illuminance | ≤10000Lux |
| Operating Voltage | 12~24V DC±10% |
| No load current | 40mA |
| Load Current | 100mA |
| Residual voltage | ＜2V@1L=100mA |
| Switch frequency | 10KHz |
| Protection | Reversed Polarity Protection, Ouptut Short-circuit Protection, Interference suppression |
| Operating Temperature | -20~+55℃ |
| Storage Temperature | -30~﹢80℃ |
| Protection Degree | IP65 |
| Material | Aluminum, Glass |
| Wiring Method | M8 4 Pin Connector |
| Weight | 55g to 128g |
| Model | KLM06-0806NP |
| Groove depth | 59mm |
| Slot width | 80mm |
| Sensing distance | 80mm |
| Min detector diameter | 0.05mm |
| Output Type | NPN&PNP Open collector |
| Switch Mode | L.on ( Light.ON )/D.on ( Dark.ON ) Can be customized |
| Emitting Light | Laser(670mm) Modulated light，class1 |
| Ambient illuminance | ≤10000Lux |
| Operating Voltage | 12~24V DC±10% |
| No load current | 40mA |
| Load Current | 100mA |
| Residual voltage | ＜2V@1L=100mA |
| Switch frequency | 10KHz |
| Protection | Reversed Polarity Protection, Ouptut Short-circuit Protection, Interference suppression |
| Operating Temperature | -20~+55℃ |
| Storage Temperature | -30~﹢80℃ |
| Protection Degree | IP65 |
| Material | Aluminum, Glass |
| Wiring Method | M8 4 Pin Connector |
| Weight |
| Model | KLM06-0506NP |
| Groove depth | 59mm |
| Slot width | 50mm |
| Sensing distance | 50mm |
| Min detector diameter | 0.05mm |
| Output Type | NPN&PNP Open collector |
| Switch Mode | L.on ( Light.ON )/D.on ( Dark.ON ) Can be customized |
| Emitting Light | Laser(670mm) Modulated light，class1 |
| Ambient illuminance | ≤10000Lux |
| Operating Voltage | 12~24V DC±10% |
| No load current | 40mA |
| Load Current | 100mA |
| Residual voltage | ＜2V@1L=100mA |
| Switch frequency | 10KHz |
| Protection | Reversed Polarity Protection, Ouptut Short-circuit Protection, Interference suppression |
| Operating Temperature | -20~+55℃ |
| Storage Temperature | -30~﹢80℃ |
| Protection Degree | IP65 |
| Material | Aluminum, Glass |
| Wiring Method | M8 4 Pin Connector |
| Weight | 55g to 128g |
