| Model | ELS-H05 |
| Sensing method | Reflective |
| Sensing distance | 20~50mm( Display：0.00~30.00) |
| Spot size | φ0.8mm |
| Min detection height difference | 0.08mm |
| Repeat accuracy | 0.01mm( Display：0.01) |
| Output Type | Open collector(NPN/PNP ),≤100mA/24V DC Residual voltage1.8V |
| Switch Mode | L.on ( Light.ON )/D.on ( Dark.ON ) Selectable output types |
| Indicator | Laser Indicator: green ， Ouptut Indicator: Orange; Mode Indicator: Red |
| Digital indicator | 7 segment 4 digit LED display |
| External input | Laser OFF, Teaching, Sample & Hold, One shot |
| Response Time | ≤1.5 ms |
| Delay Timer | OFF / On delay / Off delay / One shot (0~9999ms) |
| Sensing distance Adjust | Teaching / Manual |
| Emitting Light | Laser (655nm ),Max 390uW |
| Laser class | Class1 |
| Operating Voltage | DC 12~24V ±10% |
| Current Consumption | ≤40mA |
| Protection | Reversed Polarity Protection, , Over-current Protection |
| Ambient illuminance | Incandescent lamp<5000 lux |
| Operating Temperature | -10~+50℃, No freezing |
| Operating Humid | 35~85%RH, No freezing |
| Protection Degree | IP 67 |
| Material | Case : ＜Alminum type＞ Aluminum / ＜SUS type＞ SUS Front lens : PPSU Display : PET |
| Wiring Method | 2M 4-wires cable |
