| Model | EST-T200P |
| Sensing method | Retroreflective- Coaxial |
| Sensing distance | 2m |
| Spot size | φ60mm/2m |
| Output Type | PNP Open collector,≤100mA/30V DC |
| Switch Mode | L.on ( Light.ON )/D.on ( Dark.ON ) Selectable output types |
| Indicator | Ouptut Indicator: Orange |
| Response Time | ＜0.5ms |
| Emitting Light | Red LED |
| Operating Voltage | 10~30V DC±10% |
| Current Consumption | ＜20mA |
| Ambient illuminance | Sunlight≤10000 lux, Incandescent lamp≤3000 lux |
| Operating Temperature | -25℃~+55℃, No freezing |
| Operating Humid | 35%~85%RH , No freezing |
| Protection Degree | IP 67 |
| Material | Anti-bacterial ABS (housing), PMMA (lens) |
| Wiring Method | 2M 3-wires cable |
| Model | EST-T200N |
| Sensing method | Retroreflective- Coaxial |
| Sensing distance | 2m |
| Spot size | φ60mm/2m |
| Output Type | NPN Open collector,≤100mA/30V DC |
| Switch Mode | L.on ( Light.ON )/D.on ( Dark.ON ) Selectable output types |
| Indicator | Ouptut Indicator: Orange |
| Response Time | ＜0.5ms |
| Emitting Light | Red LED |
| Operating Voltage | 10~30V DC±10% |
| Current Consumption | ＜20mA |
| Ambient illuminance | Sunlight≤10000 lux, Incandescent lamp≤3000 lux |
| Operating Temperature | -25℃~+55℃, No freezing |
| Operating Humid | 35%~85%RH , No freezing |
| Protection Degree | IP 67 |
| Material | Anti-bacterial ABS (housing), PMMA (lens) |
| Wiring Method | 2M 3-wires cable |
