| Model | PM18-R300PR |
| Sensing method | Retroreflective |
| Sensing distance | 300cm( Non-Adjust) |
| Repeat accuracy | ＜5% |
| Output Type | PNP Open collector, Normally Open+ Normally Closed |
| Indicator | Yellow LED |
| Response Time | ≤8.2ms |
| Emitting Light | Red LED (880nm ) |
| Operating Voltage | 12~30V DC |
| Voltage drop | ≤2.5V |
| Current Consumption | ≤25mA |
| Load Current | ≤200mA |
| Protection | Reversed Polarity Protection/ Surge Protection/ Short-circuit Protection |
| Operating Temperature | -15℃~+55℃, No freezing |
| Operating Humid | 35%~95%RH , No freezing |
| Protection Degree | IP 67 |
| Material | Nickel plated brass |
| Wiring Method | 2M 4-wires cable |
| Model | PM18-R300PO |
| Sensing method | Retroreflective |
| Sensing distance | 300cm( Non-Adjust) |
| Repeat accuracy | ＜5% |
| Output Type | PNP Open collector, Normally Open |
| Indicator | Yellow LED |
| Response Time | ≤8.2ms |
| Emitting Light | Red LED (880nm ) |
| Operating Voltage | 12~30V DC |
| Voltage drop | ≤2.5V |
| Current Consumption | ≤25mA |
| Load Current | ≤200mA |
| Protection | Reversed Polarity Protection/ Surge Protection/ Short-circuit Protection |
| Operating Temperature | -15℃~+55℃, No freezing |
| Operating Humid | 35%~95%RH , No freezing |
| Protection Degree | IP 67 |
| Material | Nickel plated brass |
| Wiring Method | 2M 3-wires cable |
| Model | PM18-R300PC |
| Sensing method | Retroreflective |
| Sensing distance | 300cm( Non-Adjust) |
| Repeat accuracy | ＜5% |
| Output Type | PNP Open collector, Normally Closed |
| Indicator | Yellow LED |
| Response Time | ≤8.2ms |
| Emitting Light | Red LED (880nm ) |
| Operating Voltage | 12~30V DC |
| Voltage drop | ≤2.5V |
| Current Consumption | ≤25mA |
| Load Current | ≤200mA |
| Protection | Reversed Polarity Protection/ Surge Protection/ Short-circuit Protection |
| Operating Temperature | -15℃~+55℃, No freezing |
| Operating Humid | 35%~95%RH , No freezing |
| Protection Degree | IP 67 |
| Material | Nickel plated brass |
| Wiring Method | 2M 3-wires cable |
| Model | PM18-R300NR |
| Sensing method | Retroreflective |
| Sensing distance | 300cm( Non-Adjust) |
| Repeat accuracy | ＜5% |
| Output Type | NPN Open collector, Normally Open+ Normally Closed |
| Indicator | Yellow LED |
| Response Time | ≤8.2ms |
| Emitting Light | Red LED (880nm ) |
| Operating Voltage | 12~30V DC |
| Voltage drop | ≤2.5V |
| Current Consumption | ≤25mA |
| Load Current | ≤200mA |
| Protection | Reversed Polarity Protection/ Surge Protection/ Short-circuit Protection |
| Operating Temperature | -15℃~+55℃, No freezing |
| Operating Humid | 35%~95%RH , No freezing |
| Protection Degree | IP 67 |
| Material | Nickel plated brass |
| Wiring Method | 2M 4-wires cable |
| Model | PM18-R300NO |
| Sensing method | Retroreflective |
| Sensing distance | 300cm( Non-Adjust) |
| Repeat accuracy | ＜5% |
| Output Type | NPN Open collector, Normally Open |
| Indicator | Yellow LED |
| Response Time | ≤8.2ms |
| Emitting Light | Red LED (880nm ) |
| Operating Voltage | 12~30V DC |
| Voltage drop | ≤2.5V |
| Current Consumption | ≤25mA |
| Load Current | ≤200mA |
| Protection | Reversed Polarity Protection/ Surge Protection/ Short-circuit Protection |
| Operating Temperature | -15℃~+55℃, No freezing |
| Operating Humid | 35%~95%RH , No freezing |
| Protection Degree | IP 67 |
| Material | Nickel plated brass |
| Wiring Method | 2M 3-wires cable |
| Model | PM18-R300NC |
| Sensing method | Retroreflective |
| Sensing distance | 300cm( Non-Adjust) |
| Repeat accuracy | ＜5% |
| Output Type | NPN Open collector, Normally Closed |
| Indicator | Yellow LED |
| Response Time | ≤8.2ms |
| Emitting Light | Red LED (880nm ) |
| Operating Voltage | 12~30V DC |
| Voltage drop | ≤2.5V |
| Current Consumption | ≤25mA |
| Load Current | ≤200mA |
| Protection | Reversed Polarity Protection/ Surge Protection/ Short-circuit Protection |
| Operating Temperature | -15℃~+55℃, No freezing |
| Operating Humid | 35%~95%RH , No freezing |
| Protection Degree | IP 67 |
| Material | Nickel plated brass |
| Wiring Method | 2M 3-wires cable |
