| Model | PA1-NP | |||
| Emitting Light | Red LED(680nm) | |||
| Operating Voltage | DC 12～24V | |||
| Load Current | 100mA max | |||
| Current Consumption | 40mA Max | |||
| Output Type | NPN/PNP Open collector | |||
| Switch Mode | L.on ( Light.ON )/D.on ( Dark.ON ) Can be customized | |||
| Indicator | Ouptut Indicator： Red LED Power Indicator： green LED | |||
| Response Time | 1ms | |||
| Sensitivity setting | 20 turns trimmer | |||
| Operating Temperature | -10°C～＋60°C | |||
| Operating Humid | 35～85% RH | |||
| Protection | Reversed Polarity Protection， Over-current Protection | |||
| Insulation Resistance | 20MΩmin/DC 500V | |||
| Voltage Withstandabiligy | AC 500V 60Hz/ 60 Sec. | |||
| Protection Degree | IP50 | |||
| Material | ABS | |||
| Wiring Method | 2M/3-Wires | |||
| Weight | Approx65g ( Include Wires ) | |||
