| Model | ESN-H10P |
| Detecting face | Head-on |
| Sensing method | Reflective |
| Sensing distance | 10cm |
| Output Type | PNP Open collector,≤100mA/30V DC |
| Switch Mode | L.on ( Light.ON )/D.on ( Dark.ON ) Selectable output types |
| Indicator | Ouptut Indicator: Orange； Indicator : green |
| Response Time | 0.5 ms |
| Switch hysteresis | 15% |
| Sensitivity setting | Teach-in (Available Remote Teach-in) |
| Emitting Light | green LED |
| Operating Voltage | 12~24V DC±10% |
| Current Consumption | ＜10mA |
| Ambient illuminance | Sunlight≤10000 lux, Incandescent lamp≤3000 lux |
| Operating Temperature | -25℃~+55℃, No freezing |
| Operating Humid | 35%~95%RH , No freezing |
| storage Temperature | -40℃~+70℃, No freezing |
| storage Humid | 35%~95%RH , No freezing |
| Insulation Resistance | ≥20Ω(500V DC) |
| Shock resistance | 100G(1000m/s2),XYZ each direction |
| Noise resistance | Level 3 |
| Vibration resistance | 10~55Hz amplitude 1.5mm，XYZ， 2 hours |
| Protection Degree | IP 67 |
| Material | Shell：PBT， Lens：PMMA |
| Wiring Method | 2M 3-wires cable |
| Model | ESN-H10N |
| Detecting face | Head-on |
| Sensing method | Reflective |
| Sensing distance | 10cm |
| Output Type | NPN Open collector,≤100mA/30V DC |
| Switch Mode | L.on ( Light.ON )/D.on ( Dark.ON ) Selectable output types |
| Indicator | Ouptut Indicator: Orange； Indicator : green |
| Response Time | 0.5 ms |
| Switch hysteresis | 15% |
| Sensitivity setting | Teach-in (Available Remote Teach-in) |
| Emitting Light | green LED |
| Operating Voltage | 12~24V DC±10% |
| Current Consumption | ＜10mA |
| Ambient illuminance | Sunlight≤10000 lux, Incandescent lamp≤3000 lux |
| Operating Temperature | -25℃~+55℃, No freezing |
| Operating Humid | 35%~95%RH , No freezing |
| storage Temperature | -40℃~+70℃, No freezing |
| storage Humid | 35%~95%RH , No freezing |
| Insulation Resistance | ≥20Ω(500V DC) |
| Shock resistance | 100G(1000m/s2),XYZ each direction |
| Noise resistance | Level 3 |
| Vibration resistance | 10~55Hz amplitude 1.5mm，XYZ， 2 hours |
| Protection Degree | IP 67 |
| Material | Shell：PBT， Lens：PMMA |
| Wiring Method | 2M 3-wires cable |
