| No.Model | SL-205PA-W |
| Appearance | L shape |
| Sensing distance | 5mm (Slot width) |
| Standard detection objects | Opaque (Size:＞2.0*2.0mm) |
| Repeat accuracy | ＜0.03mm |
| Output type | PNP open-collector |
| Switch type | Selectable L.on, D.on |
| Indicator | Light off when objects are detected; light on when no ojects are detected |
| Response frequency | 3KHz |
| Light source | Infrared LED (940nm) |
| Operating voltage | 5~24V DC |
| Voltage drop | ＜1V(Load current 50mA) |
| No-load supply current | ≤15mA |
| Protective circuit | Surge protection , Reverse polarity protection |
| Ambient illuminance | ＜1000 lux (Illuminated surface of incandecent lamp) |
| Ambient temperature | Operating temp:-25℃~+55℃, storage temp: -30℃~+80℃ no freezing |
| Ambient humidity | Working Humidity: 5%~85% storage humidity: 5%~95%, no coagulating |
| Withstand voltage | AC, 1000V for 1 minute, between all power connection terminals and housing |
| Anti-vibration | 10~55Hz, Amplitude1.5mm, x, y, z three directions 2 hours each |
| Insulation resistance | 20MΩ or more between all power connection terminals and housing (based on DC250V) |
| Protection class | IP50 |
| Material | PC |
| Connection | 2M 4core cable |
