| Model | ESL-X08PO |
| Detecting face | Facade |
| Sensing method | Limited Reflective |
| Sensing distance | 3-8mm |
| Spot size | φ10mm/8mm |
| Switch hysteresis | White paper:10% |
| Output Type | PNP Open collector |
| Switch Mode | L.on ( Light.ON ) |
| Indicator | Ouptut Indicator: Orange； Indicator : green ； Power Indicator: Red |
| Response Time | ≤0.5 ms |
| Warm-up time | 15 ms |
| Operating Voltage | 12~24V DC±10% |
| Current Consumption | ≤20mA |
| Protection | Over-current Protection保护， Reversed Polarity Protection， Short-circuit Protection |
| Ambient illuminance | Sunlight≤10000 lux, Incandescent lamp≤3000 lux |
| Operating Temperature | -25℃~+55℃， No freezing |
| Operating Humid | 35%~85%RH No freezing |
| Storage Temperature | -40℃~+70℃， No freezing |
| Storage humidity | 35%~95%RH No freezing |
| Vibration resistance | 1000m/s X-Y-Z each for 2 hours |
| Shock resistance | 10~55Hz amplitude 1.5mm X-Y-Z 2 hours |
| Protection Degree | IP 67 |
| Material | PC |
| Wiring Method | 2M/3-wires cable |
