| Model | MD18-35V |
| Sensing method | Ultrasonic Reflective |
| Working Range | 50~400 mm |
| Measuring Range | 350 mm |
| Reproducibility maximum | 1 mm |
| Linearity Deviation | 5 mm |
| Resolution | 0.1mm |
| Ultrasonic Frequency | 300kHz |
| Opening Angle | 12° |
| Service Life(Tu=+25℃) | 100000 h |
| Switching Hysteresis | 2 mm |
| Supply Voltage | 18~30V DC |
| Current Consumption(Ub=24V) | 30 mA |
| Switching Frequency | 20 Hz |
| Response Time | 25 ms |
| Temperature Range | -25~60℃ |
| Switching Outputs | 1 |
| Switching Output Voltage Drop | 2.5 V |
| PNP Switching Output/Switching Current | 100 mA |
| Analog Output | 0~10V |
| Synchronous Mode | up to 40 sensors |
| Short Circuit Protection | Yes |
| Reversed Polarity Protection | Yes |
| Overload Protection | Yes |
| Lockable | Yes |
| Interface | IO-Link |
| IO-Link Version | 1.0 |
| Protection Class | III |
| Setting Method | Teach-In |
| Material | Stainless steel |
| Protection Degree | IP 67 |
| PNP NO/NC switchable | Yes |
| Connection | M12*1.0 Connector；4/5 Pin |
