| Model | TJN12-04PO |
| Type | Non-Shielded |
| Size | M12 |
| Sensing distance | 4mm±10% |
| Material | Nickel plated brass |
| Operating Voltage | 10~30V DC |
| Voltage drop | ＜2.0V |
| Load Current | 200mA |
| No load current | ＜10mA(24V) |
| Output Type | PNP Open collector， Normally Open |
| Switch frequency | 500Hz |
| Repeat accuracy | ＜1.0%(Sr) |
| Hysteresis | ＜15%(Sr) |
| Material active face | PBT |
| Operating Temperature | -25℃~+70℃ |
| Protection | Short-circuit Protection |
| Shell Protection Degree | IP 68 |
| Connection | PVC cable/2M；3*0.34mm² |
| Model | TJN12-04PC |
| Type | Non-Shielded |
| Size | M12 |
| Sensing distance | 4mm±10% |
| Material | Nickel plated brass |
| Operating Voltage | 10~30V DC |
| Voltage drop | ＜2.0V |
| Load Current | 200mA |
| No load current | ＜10mA(24V) |
| Output Type | PNP Open collector， Normally Closed |
| Switch frequency | 500Hz |
| Repeat accuracy | ＜1.0%(Sr) |
| Hysteresis | ＜15%(Sr) |
| Material active face | PBT |
| Operating Temperature | -25℃~+70℃ |
| Protection | Short-circuit Protection |
| Shell Protection Degree | IP 68 |
| Connection | PVC cable/2M；3*0.34mm² |
| Model | TJN12-04NO |
| Type | Non-Shielded |
| Size | M12 |
| Sensing distance | 4mm±10% |
| Material | Nickel plated brass |
| Operating Voltage | 10~30V DC |
| Voltage drop | ＜2.0V |
| Load Current | 200mA |
| No load current | ＜10mA(24V) |
| Output Type | NPN Open collector， Normally Open |
| Switch frequency | 500Hz |
| Repeat accuracy | ＜1.0%(Sr) |
| Hysteresis | ＜15%(Sr) |
| Material active face | PBT |
| Operating Temperature | -25℃~+70℃ |
| Protection | Short-circuit Protection |
| Shell Protection Degree | IP 68 |
| Connection | PVC cable/2M；3*0.34mm² |
| Model | TJN12-04NC |
| Type | Non-Shielded |
| Size | M12 |
| Sensing distance | 4mm±10% |
| Material | Nickel plated brass |
| Operating Voltage | 10~30V DC |
| Voltage drop | ＜2.0V |
| Load Current | 200mA |
| No load current | ＜10mA(24V) |
| Output Type | NPN Open collector， Normally Closed |
| Switch frequency | 500Hz |
| Repeat accuracy | ＜1.0%(Sr) |
| Hysteresis | ＜15%(Sr) |
| Material active face | PBT |
| Operating Temperature | -25℃~+70℃ |
| Protection | Short-circuit Protection |
| Shell Protection Degree | IP 68 |
| Connection | PVC cable/2M；3*0.34mm² |
